Explosion Proof Packaged Cooling Unit, Split Unit

Marc MS-M Series   Mini Split Air Conditioner and Heat Pump Systems

Manufactured to Order  for Use in Industrial and/or Hazardous Applications

Cooling Capacity :   12,000~ 36,000 Btu/h (3.5Kw ~ 10.5 Kw)

Heating Capacity :   14,000~ 38,000 Btu/h (4.1Kw ~ 11.1 Kw)

INCLUDES:

CMS-M series condenser units WAM-M series evaporator units

STANDARD FEATURES:

Ductless air handler with directional supply air diffuser grille

100% re-circulated indoor air

Robust stainless steel cabinet and chassis construction

Minimal building wall cut-out requirement

Spark resistant construction

EPA approved, HFC type refrigerants

Mechanical thermostat shipped loose for wall installation in the field

Disposable, MERV 5 rated, washable return air filter

Tool-less access to return air filter

OPTIONS:

Nominal cooling up to 3 tons

Single phase operation in 60 or 50 Hz applications

Configurable for operation in various non-hazardous and hazardous

rated locations

Electric heat for heating or de-humidification

Low/High ambient packages available for operation in extreme

environments

Corrosion resistant coatings for refrigerant coils and tubing

Protective component coatings for operation in corrosive environments

Digital thermostat (shipped loose) for general purpose applications

Electrical disconnects

APPLICATIONS:

Split hazard locations

E.g.: Class I, Division 2 indoor; non-hazardous outdoor

Blast/fire rated buildings

Control rooms/cabins, living quarters, plant office buildings,

and other manned applications
