Shield Air Solution Explosion Proof Exterior Wall Mounted Cooling Unit , Rooftop Unit
Marc R Series Window Unit Air Conditioning and Heat Pump for Use in Industrial and/or Hazardous Applications
Marc R Series Window Unit Air Conditioning and Heat Pump
for Use in Industrial and/or Hazardous Applications
Cooling Capacity : 6,000~ 36,000 Btu/h (1.75Kw ~ 10.5 Kw)
Heating Capacity : 66,000~ 38,000 Btu/h (1.9Kw ~ 11.2 Kw)
STANDARD FEATURES:
*Certified by CSA (bearing the CSA mark) for compliance to applicable
codes and standards
100% re-circulated indoor air
Self-contained with integral controls
Spark resistant construction
EPA approved, HFC type refrigerants
Tool-less access to return air filter
Fully insulated supply plenum for quite operation
Protective coatings for prolonged life of cabinet and chassis
OPTIONS:
Nominal cooling up to 3 tons
Heat pump operation [WARNING: heat pump systems are not suited for
heating operation in ambient temperatures lower than 45°F (7°C)]
Steam heating coil with connections
General purpose electric heat for purged cabins
Single phase operation in 60 or 50 Hz applications
Available for operation in various non-hazardous and hazardous rated locations
Type 304 or 316 stainless steel cabinet and chassis for corrosion protection
Corrosion resistant coatings for refrigerant coils and tubing (proven to withstand
10,000 hours of salt spray test)
Protective component coatings for prolonged life in corrosive environments
Auto-changeover heat/cool thermostat for unattended, year-round comfort
Low volume fresh air intake (for barometric relief only)
APPLICATIONS:
Storage sheds, analyzer shelters
Guard shacks, operator cabins, portable offices, living quarters, and other small, manned enclosures & buildings
*Certification may not apply to all configurations. Please contact our technical sales department for more information.
